ATC-GD2V2C (205- 252 MHz DIRECTIONAL DIPOLE 5 dBd)

Get a Quote Download Product Datasheet

Electrical Specifications

Frequency Range
205- 252 MHz
Gain
5 dBd
Nominal Impedance
50 Ω
VSWR
<1.5:1 (14 dBd)
Passive IM 3rd Order (2x20W)
-150 dBc
Peak Instantaneous Power
25 kW
Power Input
500 W
Vertical Beamwidth
37˚

Mechanical Specifications

Weight (lbs)
48
Dimensions (in)
4.00 x 19.00 x 144.00
